Association of Industrial Water Users of Contra Costa and Solano Counties | April 12th, 1928
Summary
PENETRATION OF SALT WATER IN UPPER BAY AND LOWER RIVER REGiON
Under natural conditions, Carquinez Straits marked, approximately, the boundary between salt and fresh
PENETRATION OF SALT WATER IN UPPER BAY AND LOWER RIVER REGiON
Under natural conditions, Carquinez Straits marked, approximately, the boundary between salt and fresh water in the upper San Francisco Bay and delta region of the two tributary rivers-the Sacramento and San Joaquin. Ordinarily salt water was present below the straits and fresh water was present above. Native vegetation in the tide marshes was predominantly of salt water types around San Pablo Bay and of fresh water types around Suisun Bay.
In tidal waters, into which run fresh water streams of variable flow, there is an ebb and flow of salt water and the zone of mixing will move up and down stream as the fresh water flow increases and decreases. For short intervals in late summer of years of minimum flow, salt water penetrated the lower river and delta region, and in wet seasons the upper bay was fresh, part of the time, to the Golden Gate. This variation in quality of water was not, however, of sufficient duration to affect the characteristic vegetation growth of the regions on each side of the straits, nor to change the designation of Suisun Bay as ordinarily a fresh water body and San Francisco Bay as salt water.
The works of man have changed conditions in many ways. The most important changes have been brought about gradualJy,-so slowly as to be hardly noticeable. The dry season of 1918,-when large summer diversions for irrigation in the Sacramento Valley resulted in the sudden penetration of salt water farther upstream than ever known before, at such an early period in summer first brought the salt water problem to public notice. The slow effects of increasing diversions in previous years had escaped notice, but were brought prominently to the attention of the inhabitants of the upper bay and delta regions in this year. Since 1918, the dry years of 1920, 1924- and 1926 have more convincingly demonstrated the importance of the salt water problem.
An accurate picture of natural conditions is not possible, because no records have been collected on which such a picture can be based, but very close approximations can be made. The log of the distance traveled by the water barge of the California Hawaiian Sugar Company in going upstream to obtain fresh water has been kept since 1908. These figures give the means of determining approximately the conditions during that period. In 1908 irrigation had been extensively developed in both valleys and conditions then were not natural. For an estimate of earlier conditions we must go to the stream flow records of the tributary streams before important diversions are taken out. It is the practice of the Sugar Company to send the barge upstream until water of approximately 50 to 70 parts per million chlorine is reached. The crew of the barge are equipped with apparatus by which water is analyzed until this degree of purity is reached. Since trips are made nearly every day during the summer months, the record is a very good indication of the point reached by salt water. A summary of the complete records shows the fluctuation of the line between fresh and salt water. Records of the Sugar Company arc attached. (Table 1.)
The Sugar Company requires water of great purity. For irrigation, domestic or ordinary industrial uses, water of a lesser degree of purity may be used. A comparison of the point where the Sugar Company's barge is filled with the point where the remaining uses could be satisfied, indicates that from five to ten miles downstream from the place where the barge turns, water could be obtained satisfactory for domestic supply. Making an allowance of 7 1/2 miles in the average records, we find that an average flow of 5,000 second feet in both streams will maintain fresh water at Collinsville; 7,000 second feet will maintain fresh water at the San Francisco-Sacramento ferry.
If we sum up the flow of the important tributaries of the Sacramento and San Joaquin rivers at the points where these streams leave the mountains and assume that this flow under natural conditions would have reached the head of the Suisun Bay we will find that at no time in the past ten years would the average monthly flow have been Jess than 5,100 second feet. It is probable, should all streams be running in a natural way, that salt water would have penetrated no farther in this extremely dry period than Antioch, and then only for a few days at a time.
It is not possible to make a more detailed study of this condition without making a number of assumptions as to speed of flow from the gaging stations to the head of the bay, and there is little accurate information on which the assumptions may be made. The definite statement that salt water under natural conditions did not penetrate higher upstream than the mouth of the river, except in the driest years and then only for a few days at a time, is warranted. (See Table 2 for monthly flow of tributary streams.)
At present salt water reaches Antioch every year, in two-thirds of the years running further upstream. It is to be expected that it will continue to do so in future, even in years of greatest runoff. In other words, the penetration of salt water has become a permanent phenomenon in the lower river region.
